LAPP KABEL ÖLFLEX® Crane 2S Cable, UV and mechanical resistant, Flame-retardant

LAPP KABEL



LAPP KABEL LOGO

Flexible at cold temperatures, PVC cables with external steel supporting elements

  • Two steel support elements that are integrated into the outer sheath on opposite sides absorb the tensile forces during operation
  • Tensile strength of 2100 N per supporting element
Application range
  • For connecting movable control panels and consoles
  • As a self-supporting shaft cable; in high rack systems
  • Suitable for outdoor applications
  • Do not use for lift applications!
Product Features
  • Flame-retardant according IEC 60332-1-2
  • Flexible at low temperatures
  • Based on VDE 0250
    Product Make-up
    • Strands of bare copper wires
    • Special PVC-based core insulation
    • Special textile wrapping to improve sliding movement between the sheath and cores
    • Special PVC-based outer sheath
    • Opposing, integrated steel supporting elements
