ifm E12261 - M12 Wirable Field Plug, Female, Gold-Plated Contacts
ifm E12261 - M12 Wirable Field Plug, Female, Gold-Plated Contacts
Regular price
$45.80
Sale price
$45.80
Regular price
$50.60
Unit price
per
Tax included.
E12261
6 in stock
The ifm E12261 is a wirable M12 field-attachable plug for assembling custom cordsets on site, featuring gold-plated contacts for a reliable, low-resistance connection.
- Female M12 connector, straight, A-coded
- Screw terminals, accepts cable sheath Ø 6-8 mm, conductors up to 0.75 mm²
- Gold-plated contacts, silicone-free construction
- Diecast zinc, nickel-plated body and locking nut (brass, nickel-plated)
- Shieldable cable connection
- Protection rating IP67
- Operating temperature -25°C to 85°C
- Operating voltage <250V AC/DC, max. current load 4A (to 40°C)
Specifications
| Connector | M12, straight, A-coded, female |
| Termination | Screw terminals, up to 0.75 mm² |
| Cable sheath | Ø 6-8 mm |
| Contacts | Gold-plated |
| Operating voltage | <250V AC/DC |
| Max. current load | 4A (to 40°C) |
| Protection rating | IP67 |
| Ambient temperature | -25°C...85°C |
| Material | Diecast zinc, nickel-plated; nut: brass, nickel-plated |
| Dimensions | 20 x 20 x 62 mm |
| Weight | 44.5 g |
