New Klaxon Flashguard Beacons - LED, IP65

$154.00

QBS-0300

Voltage 10-30VDC (Flashing or Static) 230VAC (Flashing Only)

Color: Red

Flashguard weatherproof LED beacons are ideal visual indicators in a variety of applications.

Flashguard high effective beacons are ideal visual indicators in a variety of applications. Utilising modern LED components to provide a flash that matches or improves on previous designs and technologies whilst offering longer expected component life.

All Flashguard beacons are fitted with a diffuser for greater visibility and spread of light. DC versions offer the ability to wire for flashing or static operation in a single unit and two useful distinct styles to support intented use.

Standard: includes a terminal block and a 27mm deep base supplied with a seal and grommet.

Compact, ultra modern sleek appearance
Ease of installation with first-fix option on standard models
Weatherproof to IP65
White, high quality polycarbonate housing
Vandal-resistant safety locking mechanism
10-30VDC (Flashing or Static), 230VAC (Flashing Only)

Part No	Style	Lens Colour	Voltage	Current
QBS-0300	Standard	Red	10-30V DC	30mA
QBS-0301	Standard	Amber	10-30V DC	30mA
QBS-0302	Standard	Clear	10-30V DC	30mA
QBS-0303	Standard	Blue	10-30V DC	30mA
QBS-0304	Standard	Green	10-30V DC	30mA
QBS-0310	Standard	Red	230V AC	35mA
QBS-0311	Standard	Amber	230V AC	35mA
QBS-0312	Standard	Clear	230V AC	35mA
QBS-0313	Standard	Blue	230V AC	35mA
QBS-0314	Standard	Green	230V AC	35mA

Specifications

Current: 10-30VDC (30mA) 230VAC (35mA)
Flash Rate: 1Hz
Operating Temp: -20ºC to +60ºC
IP Rating: IP65
Construction: High impact Polycarbonate
Weight: 0.14kg

Dimensions

Klaxon Flashguard Beacon Data Sheet
