New Klaxon Nexus 105 Sounder/Beacon, LED - 113dB (max); 105dB (typical), IP66, 64 Tones

$539.00

Tax included.

PNC-0201

Voltage 10-60VDC 110/230VAC

Beacon Colour: Red

The Nexus 105 is a high output, low current consumption sounder beacon designed for industrial applications.

Connections are made to the base during the initial wiring phase which results in faster and more reliable installation.

In addition, the head is fixed by quarter turn fasteners avoiding the need to screw up four individual screws thus enabling faster installation and accurate seal compression for weatherproofing.

The combination of a powerful sounder and high output LED beacon ensures a very effective audio-visual signal.

High output LED beacon
105dB, 110dB and 120dB options
Quarter turn fasteners for ease of installation
First-fix, wire to base technology
IP66 rated
Three alarm stages
Volume control for greater flexibility - 20dB
64 tones
AC or DC options

Audio Tone Sample Chart - Click Here

Part No.	Lens Colour	Voltage	Sounder Current	Beacon Current
PNC-0216	Red Beacon	110/230V AC	40mA (max)	55mA
PNC-0217	Amber Beacon	110/230V AC	40mA (max)	55mA
PNC-0218	Clear Beacon	110/230V AC	40mA (max)	55mA
PNC-0219	Blue Beacon	110/230V AC	40mA (max)	55mA
PNC-0220	Green Beacon	110/230V AC	40mA (max)	55mA
PNC-0201	Red Beacon	10-60V DC	8-40mA	55mA
PNC-0202	Amber Beacon	10-60V DC	8-40mA	55mA
PNC-0203	Clear Beacon	10-60V DC	8-40mA	55mA
PNC-0204	Blue Beacon	10-60V DC	8-40mA	55mA
PNC-0205	Green Beacon	10-60V DC	8-40mA	55mA
