Sprecher + Schuh CS7-PV-04 Auxiliary Contact

Sprecher + Schuh CS7-PV-04 Auxiliary Contact

Sprecher + Schuh

$93.50
$93.50 $119.50
Tax included.

CS7PV04

1 in stock

S+S CS7 Auxiliary Contact with 4NC Contacts Top Mount

The Sprecher + Schuh CS7 Industrial Control Relays share the same modern design as the CA7 contactor range. Compact and built for heavy-duty industrial control applications where reliability and versatility are essential and available as either standard, master and bifurcated models.

Specifications

Number of contacts as normally closed contact: 4
Rated insulation voltage Ui: 690 V
Rated operation current Ie at 40 °C Tu: 10 A
Rated operation current Ie at AC-15, 24 V: 6 A
Rated operation current Ie at AC-15, 120 V: 6 A
Rated operation current Ie at AC-15, 240 V: 5 A
Rated operation current Ie at AC-15, 400 V: 3 A
Rated operation current Ie at DC-12, 24 V: 12 A
Rated operation current Ie at DC-12, 110 V: 3.5 A
Rated operation current Ie at DC-12, 220 V: 0.55 A
Rated operation current Ie at DC-13, 24 V: 5 A
Rated operation current Ie at DC-13, 110 V: 1.2 A
Rated operation current Ie at DC-13, 220 V: 0.6 A
Min. contact rating current: 5 mA
Min. contact rating voltage: 17 V
Rated operation current Ie at AC-15, 230 V: 5.5 A
