theben TR608 top2 S Digital time switch with weekly program - 6080101

theben

Made in Germany

Function Description

  • Digital time switch with weekly program
  • 1 channel
  • 56 memory locations
  • DuoFix spring terminals
  • For 2 conductors each
  • Wire or strand (with or without wire end sleeve)
  • Wire diameter: 0.5 - 2.5 mm²
  • Button for releasing plug-in connection
  • Text-oriented user guidance in display
  • Preset date and time
  • fully operable without mains connection
  • Interface for OBELISK top2 memory card (PC programming)
  • 2. insertable switching program
  • Copying programs
  • Storing programs
  • 10 year power reserve (lithium battery)
  • ON-OFF switching times
  • Switching pre selection
  • Permanent switching ON/OFF
  • Integrated operating hour counter
  • Reset option
  • Service function for monitoring maintenance intervals
  • Holiday program
  • Permanent switching ON/OFF
  • PIN coding
  • Automatic summer/winter time changeover
  • can be deactivated
  • Date rule options are already stored for Europe, the USA and other countries
  • own date rule options or changeover around set dates are available

Click Here for PDF Data Sheet
