WERMA 140 Multi-Tone Sounder, 32 Tones, 115dB (max); 105dB (typical)

Werma

$176.90

Tax included.

140.150.50

Voltage 9-28VDC 110-240VAC

Housing Colour: Red

Signalling of faults or alarms in the event of danger, including standardised signal tones, e.g. from fire alarm technology.

Multi-tone siren with adjustable tones and volume

32 tones adjustable for various applications
Adjustable volume up to 115 dB
In the low-voltage version, 2 tones can be controlled externally

Specifications

Height 110mm

Diameter 100mm

Materials PC/ABS

Housing colour Red or White

Connection Screw terminals

Protection category IP65

cross-sectional area maximum 2,50mm² / 14AWG

Cable entry Through hole (M20)

Type of fixing Wall mounting

Working temperature minimum-40°C

Product weight 273g (D), 301g (AC)

Working temperature maximum+70°C

Electrical Data

9-28VDC

Operating voltage 9–28V

Operating voltage type DC

Operating voltage tolerance +/- 0%

Rated operational current 120 mA

Rated operational voltage 24 VDC

Rated inrush current 1400 mA

Protection class Protection class 2

Pollution degree 3

110-240VAC

Operating voltage 115-230V

Operating voltage type AC

Operating voltage frequency50Hz at 230V; 60Hz at 115V

Operating voltage tolerance +/- 10%

Rated operational current 40 mA

Rated operational voltage 230 VAC

Rated inrush current 1,87A

Protection class Protection class 2

Overvoltage category II

Pollution degree 3

Specifications

Height 110mm
Diameter 100mm
Materials PC/ABS
Housing colour Red or White
Connection Screw terminals
Protection category IP65
cross-sectional area maximum 2,50mm² / 14AWG
Cable entry Through hole (M20)
Type of fixing Wall mounting
Working temperature minimum-40°C
Product weight 273g (D), 301g (AC)
Working temperature maximum+70°C
